TSTC Turnstile with Face Recognition System

Views :
Update time : 2026-09-07

Turnstile with Face Recognition system is a upgrade turnstile which launched by TSTC, it has lots of features as below .

Face recognition for automatic door-TSTC

(1) Adopt advanced servo motor system and positioning system to ensure doors swing quickly, accurately, smoothly, quietly, and with low power consumption, energy saving and environmental protection.

(2) Utilized 12 pairs of military-grade infrared detectors and precise algorithms which can accurately detect the pedestrians’ passing position in the channel to achieve the functions of preventing the passage of tailgates, reverse traffic and anti-squeeze.

(3) The use of the design in infrared anti- squeeze , mechanical anti-squeeze, and the advanced industrial electric current detection anti-collision and other multiple anti-squeeze which maximize protecting pedestrians' safety.

(4) The maximum widening channel is 1000mm, which can be used as carrying baggage passages and wheelchair access.

(5) Configured dry contact signal input interface, RS485/RS232 interface, TCP/IP interface (optional) which can be compatible with various access controllers.

(6) Force feedback control function . When the door swing is impacted beyond the safe range suddenly, it can be slowly pushed for a distance to buffer the impact force of the movement and the reverse impact force received by the pedestrian, which not only protects the pedestrians but also the movement.

(7) Servo brushless motor is small ,light, with large output, fast response, high speed, small inertia, smooth rotation and stable torque. The control is complex which is easy to be intelligence. The electronic commutation mode is flexible which makes it can be changed by square wave or sine wave. The motor is maintenance-free with high efficiency, low operating temperature, low electromagnetic radiation, long life, and can be used in various environments.

(8) The system comes with a three-color status indicator light strip, and equipped with a Chinese voice system which can customize voice prompt content.

(9) Fully support the moving face recognition system which can recognize faster ,and it can recognize facial information quickly even when it is in operation.

TSTC Automatic Doors, will always work hard to provide safest products and best service to customers!
